HMC-ALH369低噪音放大器

HMC-ALH369是一款GaAs MMIC HEMT三级、自偏置、低噪声放大器芯片，工作频率范围为24至40 GHz。 该放大器提供22 dB增益，采用+5V/66 mA单偏置电源，噪声系数为2 dB。 由于尺寸较小(2.88 mm²)，HMC-ALH369放大器芯片适合集成到多芯片模块(MCM)中。

出色的噪声系数： 2.0 dB
增益： 22 dB
P1dB输出功率： +11 dBm
电源电压： +5V (66 mA)
裸片尺寸： 2.10 x 1.37 x 0.1 mm

应用

点对点无线电
点对多点无线电
相控阵
VSAT
卫星通信
