HMC-APH518功率放大器

HMC-APH518是一款两级GaAs HEMT MMIC 1 W功率放大器，工作频率范围为21至24 GHz。 HMC-APH518提供17 dB增益，采用+5V电源电压时具有+30.5 dBm输出功率（1 dB压缩）。 所有焊盘和芯片背面都经过Ti/Au金属化，放大器已完全钝化以实现可靠操作。

HMC-APH518 GaAs HEMT MMIC 1 W功率放大器兼容传统的芯片贴装方式，以及热压缩和热超声线焊工艺，非常适合MCM和混合微电路应用。 此处显示的所有数据均是芯片在50 Ω环境下使用RF探头接触测得。

输出IP3： +39 dBm
P1dB： +30.5 dBm
增益： 17 dB
电源电压： +5V
50 Ω匹配输入/输出
裸片尺寸：
4.49 x 1.31 x 0.1 mm

应用

点对点无线电
点对多点无线电
VSAT
军事和太空
